How to Build a Cabinet Carcass In 7 Steps

Save big on your dream kitchen with this next-level DIY

A kitchen with white cabinets and subway tiles
Photo: in4mal / iStock / Getty Images Plus / Getty Images
A kitchen with white cabinets and subway tiles
Photo: in4mal / iStock / Getty Images Plus / Getty Images
SKILL LEVEL
Challenging
COMPLETION TIME
7 hours
COST
$75–$120
Get quotes from up to 3 pros!
Enter a zip below and get matched to top-rated pros near you.
Geo Icon
What you'll need:
TOOLS
  • Long level
  • Power drill
  • Jigsaw
  • Pocket drill kit
  • Tape measure
SUPPLIES
  • Pocket hole screws
  • Washers
  • Choice of wood for cabinet carcass (¾" thick sheets)
  • 4 1-by-2 boards
  • Wood glue
View all

You're not the first homeowner to spend an extraordinary amount of time dreaming about what your kitchen might look like with new cabinets. Why not take that visualization exercise to new heights, and learn how to build a cabinet carcass?

A DIY build of even just the carcass can save a significant portion of your budget. Follow along for how to build a cabinet carcass in this nine-step guide.

Prepping to Build a Cabinet Carcass

Follow these prep steps to set your project up for success.

Establish Your Cabinet Carcass Dimensions

First, you'll need to figure out where your eventual cabinets will be installed in your kitchen or bathroom. Next, calculate the dimensions of your cabinet carcass. Determining your cabinet needs is the best way to get started with a project of this magnitude (and will also help you set a budget). Standard cabinet dimensions should be:

  • 34 1/2-inch height

  • 24-inch width

  • 1/4-inch gap between cabinets

A couple of factors will determine the length of your cabinets. For example, you may want to build one long cabinet without doors or drawers underneath or several drawer-equipped carcasses that can be attached later.

What Material is Best For a Cabinet Carcass?

Certain types of wood work well for cabinetry, while others, such as certain hardwoods, may expand or contract too much when hot weather strikes to be suitable as cabinets. It's important when building cabinets to know what to look for.

Some common cabinetry options include:

  • Hardwood: Cherry, maple, ash

  • Softwood: Spruce, pine

  • High-end: Walnut, mahogany

  • Most Affordable: Cabinet Plywood

Plywood is the most budget-friendly, plus it comes with the added benefit of not soaking up water easily, which is great for cabinetry.

7 Steps to Build a Cabinet Carcass

  1. Cut Your Cabinet Carcass Sides and Bases

    Your plywood sides will be 34 1/2 inches high by 22 1/2 inches in length.

    1. You'll need to make a 3-by-3-inch cut into the bottom left corner of each board as well.

    2. You'll need to repeat this step for each cabinet carcass you plan to build.

    3. Your bases will be 22 1/2 inches by whatever length you've chosen for each carcass.

    4. Remember that the width needs to be around two inches less on either side to account for the 3-by-3-inch cut you made earlier.

    5. Attach the base on both ends using pocket hole screws right below the top lip of the bottom.

  2. Attach the Boards at the Top Using Plywood Strips

    1. Use scrap plywood or leftover strips to attach the boards at the top to bring your carcass together. They don't have to be a specific size—2 to 3 inches of thickness will do just fine.

    2. Use pocket hole screws to attach.

    3. The carcass should now be able to stand on its own.

  3. Attach a Top Support Board

    1. On the backside of the top of your cabinets, attach a second piece of plywood (the same size as the last step) to the back where your cabinet carcass will meet the wall. This piece will be touching the back plywood strip.

    2. Adding this extra strip will make drilling into your support board at the wall much easier later on.

  4. Attach Your Cabinet Carcasses Together

    Suppose you're building multiple carcasses that will eventually sit side by side in the kitchen or bathroom. In that case, you may want to consider attaching them now and installing them as a unit.

    1. Each carcass should be 1/4-inch apart from the other.

    2. You can easily attach the carcasses by placing shims in between and then using pocket screws and a bead of wood glue to fix them together.

    Pro tip: You may want to avoid drilling them together if you know your floor is significantly uneven.

  5. Add a Face Frame to Each Carcass

    1. Make four cuts of your 1-by-2 strips to build a face frame for the front end of each cabinet carcass. These should fit the perimeter of the face of your cabinets while still leaving the 3-inch lip at the base. 28 inches by your width is a good guideline but may be slightly different for yours.

    2. If you are installing shelves or drawers into your cabinets, measure out half the distance from the bottom to the top and mount. You may need to adjust this based on how many cabinets or doors you're planning to install on the carcass.

  6. Establish the Low and High Points of your Floor

    Before installing your framed cabinets, you'll need to measure the floor's slope. All floors—even in a new home or kitchen that's recently been renovated—are uneven to some extent.

    1. Using a long level, figure out the high and low points on your floor where the cabinets will be installed.

    2. Draw a line on the wall at the high point marking 34 1/2-inches—the height of your cabinets–then trace across the length of the wall where your cabinet carcass will sit.

    3. Use a stud finder to mark the screw points, then install a backer board (1-by-2-inch strip) at this point.

  7. Add Shims to Level out the Cabinets

    A woman and a man building a cabinet carcass
    Photo: sturti / E+ / Getty Images

    Move your cabinet carcass into place, then level it out using wood shims on either side.

    It might be hard to level out the uneven parts in the middle of your cabinet carcass if you drilled your cabinets together. In this case, install each carcass to the wall first, level them out with shims, then attach the units together once they've all been leveled.

DIY Building a Cabinet Carcass vs. Hiring a Pro

Building a kitchen cabinet box does take some time and elbow grease. But for a couple of hundred dollars worth of plywood and materials, you can make something that would otherwise cost thousands of dollars to have installed.

Alternatively, you might simply choose to makeover your existing cabinets giving them a fresh face—staining or refacing cabinets are two ideas.

However, a local custom cabinet maker can be a resource for outsourcing your project. If it’s in range of your budget, a pro can help you plan your build, choose materials, and install them.
